Nginx Proxy Manager Install Guide for Proxmox VE 9 LXC

Run NPM in a pure Proxmox LXC - no Docker!

The NPM Installation Challenge

Nginx Proxy Manager (NPM) is primarily designed to run in Docker containers. The developers provide:

1. Docker images - Their primary distribution method

2. Docker Compose files - For easy Docker deployment

3. Source code - On GitHub, but no traditional installation packages

There are no .deb packages, no apt repository, and no official install script for bare-metal or LXC installations.

What We’re Actually Doing

Since NPM doesn’t offer a traditional installation method, this guide essentially:

1. Downloads the NPM source code from GitHub

2. Extracts the Docker container filesystem (found in docker/rootfs/)

3. Adapts Docker-specific configurations to work in a standard Linux environment

4. Manually builds the frontend (the web UI you interact with)

5. Sets up services that would normally be handled by Docker

Why Not Just Use Docker?

While Docker in LXC is possible, this native approach:

• Reduces overhead (no Docker daemon)

• Integrates better with LXC

• Provides more direct control

• Avoids nested containerization complexity

• Makes troubleshooting easier

• Pure LXC is more elegant

But honestly, it is a lot of work. I wanted to replicate the Helper Script and this is basically how it is done. I might try out Docker inside an LXC although I never like doing that.

Prerequisites

• Proxmox VE 9.x installed and running

• SSH or console access to Proxmox host

• Network connectivity for downloading packages

• An available static IP address on your network (e.g., 192.168.10.101)

• Your network gateway IP address (e.g., 192.168.10.1)

System Requirements

• CPU: 2 cores (for handling multiple proxy connections)

• RAM: 1024MB minimum (Node.js requires memory)

• Disk: 4GB minimum

• Container Type: Unprivileged (more secure)

• OS: Debian 12

Step 1: Create the LXC Container

All Step 1 commands should be run inside the Proxmox host

If you just finished up the Pi-hole guide then you will already have Debian 12 downloaded and can skip to the container creation.

Update the template cache to get the latest container templates

pveam update

List available Debian templates

pveam available | grep debian | grep -v turnkey

Download Debian 12 template to local storage

pveam download local debian-12-standard_12.12-1_amd64.tar.zst

Create the container

pct create 101 local:vztmpl/debian-12-standard_12.12-1_amd64.tar.zst \
  --hostname nginxproxymanager \
  --memory 1024 \
  --cores 2 \
  --rootfs local-lvm:4 \
  --net0 name=eth0,bridge=vmbr0,ip=192.168.10.101/24,gw=192.168.10.1 \
  --unprivileged 1 \
  --features nesting=1 \
  --onboot 1 \
  --start 1

Complete parameter explanations:

• 101: Container ID (must be unique, check existing with pct list)

• local:vztmpl/debian-12...: Template location and name

• --hostname nginxproxymanager: Container hostname for network identification

• --memory 1024: Allocate 1GB RAM (1024MB)

• --cores 2: Allocate 2 CPU cores for better performance

• --rootfs local-lvm:4: 4GB root filesystem on local-lvm storage

• --net0 name=eth0,bridge=vmbr0,ip=192.168.10.101/24,gw=192.168.10.1: Network configuration

  • name=eth0: Interface name inside container

  • bridge=vmbr0: Bridge to use (check with ip a | grep vmbr)

  • ip=192.168.10.101/24: Static IP with /24 subnet mask

  • gw=192.168.10.1: Gateway (router) IP address

• --unprivileged 1: Run as unprivileged for better security

• --features nesting=1: Enable nesting for container features

• --onboot 1: Start automatically when Proxmox boots

• --start 1: Start container immediately after creation

Verify the container was created and is running

pct status 101

Step 2: Enter Container and Initial Setup

Enter the container console

pct enter 101

Update package lists and upgrade existing packages

apt update && apt upgrade -y

Step 3: Install Base Dependencies

Install essential packages required by NPM

apt install -y \
  ca-certificates \
  apache2-utils \
  logrotate \
  build-essential \
  git \
  curl \
  wget \
  sudo \
  gnupg \
  lsb-release

Step 4: Install Python Dependencies

apt install -y \
  python3 \
  python3-dev \
  python3-pip \
  python3-venv \
  python3-cffi \
  python3-certbot \
  python3-certbot-dns-cloudflare

Install additional certbot plugins

pip3 install --break-system-packages certbot-dns-multi

Create Python virtual environment for certbot

python3 -m venv /opt/certbot/

Step 5: Install OpenResty (Nginx Fork)

Add OpenResty repository GPG key securely

wget -O - https://openresty.org/package/pubkey.gpg | \
  gpg --dearmor -o /usr/share/keyrings/openresty.gpg

Add OpenResty repository with signed-by option

echo “deb [signed-by=/usr/share/keyrings/openresty.gpg] http://openresty.org/package/debian $(lsb_release -sc) openresty” | \
  tee /etc/apt/sources.list.d/openresty.list

Update package lists and install OpenResty

apt update
apt install -y openresty

Step 6: Install Node.js via NVM

Why NVM? Node Version Manager lets us install specific Node.js versions without relying on Debian’s older packages. NPM requires a modern Node.js version.

Version Choice: We’ll install Node.js 22.x (not the absolute latest) because:

• It’s stable and well-tested

• NPM is tested against LTS versions

• LTS receives security updates for 30 months

• Newer versions might introduce breaking changes

apt install -y build-essential libssl-dev

Navigate to temporary directory

cd /tmp

Identify the latest release here https://github.com/nvm-sh/nvm/releases

Download the release

wget https://github.com/nvm-sh/nvm/archive/refs/tags/v0.40.3.tar.gz

Extract the tarball

tar -xzf v0.40.3.tar.gz

Move to install directory

cd nvm-0.40.3

Optional - View Script to Verify Validity

less install.sh

After reviewing and confirming the code is safe, run the installer

./install.sh

The installer will:

• Create ~/.nvm directory

• Add NVM loading script to ~/.bashrc

• Copy NVM files to the installation directory

Source the NVM script

export NVM_DIR=”$HOME/.nvm”
[ -s “$NVM_DIR/nvm.sh” ] && \. “$NVM_DIR/nvm.sh”
[ -s “$NVM_DIR/bash_completion” ] && \. “$NVM_DIR/bash_completion”

Verify NVM installation

nvm --version

Check Node v22 versions

nvm list-remote | grep “v22” | grep “Latest”

Install NodeJS

nvm install 22.21.1

Set up default Node

nvm use 22.21.1
nvm alias default 22.21.1

Verify Node Installation

node --version

NVM installs Node.js in user directory, but systemd services run as system processes and need Node.js in system paths. This will make it available system-wide

n=$(which node)
n=${n%/bin/node}
chmod -R 755 $n/bin/*
cp -r $n/{bin,lib,share} /usr/local/

Verify

/usr/local/bin/node --version

Cleanup

cd /tmp
rm -rf nvm-0.40.3
rm v0.40.3.tar.gz

Step 7: Install pnpm Package Manager

npm install -g pnpm@8.15

Verify

pnpm --version

Step 8: Download Nginx Proxy Manager Source

Locate the latest release https://github.com/NginxProxyManager/nginx-proxy-manager/releases. Make sure to use the one with the “Latest” tag.

Move to tmp folder

cd /tmp

Then download the latest tar file

wget https://github.com/NginxProxyManager/nginx-proxy-manager/archive/refs/tags/v2.12.6.tar.gz

Extract the tar file

tar -xzf v2.12.6.tar.gz

Enter the folder

cd nginx-proxy-manager-2.12.6

Step 9: Set Up System Environment

NPM’s source includes Docker-specific configurations that assume Docker’s filesystem layout. We need to adapt these for our standard Linux environment.

Create the required symlink (copy and paste the whole block at once)

ln -sf /usr/bin/python3 /usr/bin/python
ln -sf /usr/bin/certbot /opt/certbot/bin/certbot
ln -sf /usr/local/openresty/nginx/sbin/nginx /usr/sbin/nginx
ln -sf /usr/local/openresty/nginx/ /etc/nginx

The nginx.conf file is configured for Docker, which handles ‘daemon’ mode differently. In a normal system, we need nginx to run as a service, not a daemon.

sed -i ‘s+^daemon+#daemon+g’ docker/rootfs/etc/nginx/nginx.conf

This command:

• sed -i - Edit file in-place

• s+^daemon+#daemon+g - Find lines starting with “daemon” and comment them out

• We use + as delimiter instead of / because paths contain /

NPM’s nginx config files have includes like include conf.d/something.conf, but in our setup these need to be include /etc/nginx/conf.d/something.conf (full paths).

find “$(pwd)” -type f -name “*.conf” -exec \
  sed -i ‘s+include conf.d+include /etc/nginx/conf.d+g’ {} \;

Breaking down this complex command:

• find “$(pwd)” - Start searching from current directory (the NPM source)

• -type f - Only find files (not directories)

• -name “*.conf” - Only files ending in .conf

• -exec ... {} \; - For each found file, execute the following command

• sed -i ‘s+include conf.d+include /etc/nginx/conf.d+g’ {} - Replace the include paths

• {} - Placeholder for each found file

• \; - End of the exec command

What it does: Goes through every nginx config file and changes relative includes to absolute paths, so nginx can find the included configurations.

Step 10: Create Directory Structure

NPM expects a specific directory structure to store:

• Proxy configurations

• SSL certificates

• Temporary files

• Logs

• Cache data

Without these directories, NPM will fail to start or work properly. Copy and paste the whole command.

# Web root and nginx config directories
mkdir -p /var/www/html /etc/nginx/logs

# Nginx needs these for temporary file handling during uploads/proxying
mkdir -p /tmp/nginx/body /run/nginx

# NPM’s data directories - where your configuration is stored
mkdir -p /data/nginx /data/custom_ssl /data/logs /data/access

# Different types of hosts you can configure in NPM
mkdir -p /data/nginx/default_host     # Default site when no match
mkdir -p /data/nginx/default_www      # Default site files
mkdir -p /data/nginx/proxy_host        # Your reverse proxy configurations
mkdir -p /data/nginx/redirection_host  # URL redirects
mkdir -p /data/nginx/stream            # TCP/UDP stream proxying
mkdir -p /data/nginx/dead_host         # Disabled hosts
mkdir -p /data/nginx/temp              # Temporary files

# Nginx cache directories for performance
mkdir -p /var/lib/nginx/cache/public   # Public content cache
mkdir -p /var/lib/nginx/cache/private  # Private content cache
mkdir -p /var/cache/nginx/proxy_temp   # Temporary proxy cache

Set the appropriate permissions
Nginx needs full access to cache directory

chmod -R 777 /var/cache/nginx

Ensure root owns the temp directory

chown root:root /tmp/nginx

Step 11: Copy NPM Files to System

The docker/rootfs/ directory contains the complete filesystem that would be inside the Docker container. We need to extract and place these files in the correct locations on our system.

cp -r docker/rootfs/var/www/html/* /var/www/html/
cp -r docker/rootfs/etc/nginx/* /etc/nginx/
cp docker/rootfs/etc/letsencrypt.ini /etc/letsencrypt.ini
cp docker/rootfs/etc/logrotate.d/nginx-proxy-manager /etc/logrotate.d/nginx-proxy-manager

Create nginx configuration link

ln -sf /etc/nginx/nginx.conf /etc/nginx/conf/nginx.conf
rm -f /etc/nginx/conf.d/dev.conf

Step 12: Configure DNS Resolvers

Nginx needs to know which DNS servers to use when it proxies to domains (like when you proxy to “service.local” instead of an IP). This extracts your system’s DNS servers and formats them for nginx.

echo resolver “$(awk ‘BEGIN{ORS=” “} $1==”nameserver” {print ($2 ~ “:”)? “[”$2”]”: $2}’ /etc/resolv.conf);” \
  > /etc/nginx/conf.d/include/resolvers.conf

Breaking down this command:

• awk ‘BEGIN{ORS=” “} - Set Output Record Separator to space (instead of newline)

• $1==”nameserver” - Find lines starting with “nameserver”

• {print ($2 ~ “:”)? “[”$2”]”: $2} - If IPv6 (contains :), wrap in brackets, otherwise print as-is

• Result: Creates a line like resolver 192.168.10.1 8.8.8.8; for nginx

Step 13: Generate Dummy SSL Certificate

openssl req -new -newkey rsa:2048 -days 3650 -nodes -x509 \
  -subj “/O=Nginx Proxy Manager/OU=Dummy Certificate/CN=localhost” \
  -keyout /data/nginx/dummykey.pem \
  -out /data/nginx/dummycert.pem

Step 14: Build Frontend

NPM’s web interface is a modern JavaScript application that needs to be “built” (compiled/bundled) from source code. The source includes placeholder version numbers (0.0.0) that need to be updated.

Update version information in package files

sed -i “s|\”version\”: \”0.0.0\”|\”version\”: \”$RELEASE\”|” backend/package.json
sed -i “s|\”version\”: \”0.0.0\”|\”version\”: \”$RELEASE\”|” frontend/package.json

Build it (can take a few minutes)

cd ./frontend
pnpm install
pnpm run build
cd ..

What happens during build:

• Transpiles modern JavaScript to browser-compatible code

• Bundles all JS files into optimized chunks

• Processes CSS and images

• Creates the dist/ directory with production-ready files

Step 15: Install Application Files

Create application directory structure

mkdir -p /app/global /app/frontend/images

Copy all application files to proper locations

cp -r frontend/dist/* /app/frontend/
cp -r frontend/app-images/* /app/frontend/images/
cp -r backend/* /app/
cp -r global/* /app/global/

Step 16: Configure Database

cat <<’EOF’ >/app/config/production.json
{
  “database”: {
    “engine”: “knex-native”,
    “knex”: {
      “client”: “sqlite3”,
      “connection”: {
        “filename”: “/data/database.sqlite”
      }
    }
  }
}
EOF

Step 17: Install Backend Dependencies

cd /app
pnpm install

Step 18: Create Systemd Service

Docker would normally manage the NPM process. Since we’re not using Docker, we need systemd (the Linux service manager) to start NPM on boot and restart it if it crashes.

Create NPM service file for systemd

cat <<’EOF’ >/lib/systemd/system/npm.service
[Unit]
Description=Nginx Proxy Manager
After=network.target
Wants=openresty.service

[Service]
Type=simple
Environment=NODE_ENV=production
# The - prefix means “ignore if this fails” (dirs might already exist)
ExecStartPre=-mkdir -p /tmp/nginx/body /data/letsencrypt-acme-challenge
# Start the Node.js application with memory limit and error handling
ExecStart=/usr/local/bin/node index.js --abort_on_uncaught_exception --max_old_space_size=250
WorkingDirectory=/app
Restart=on-failure

[Install]
WantedBy=multi-user.target
EOF

Service file explanation:

• After=network.target - Wait for network to be ready

• Wants=openresty.service - Try to start OpenResty too

• NODE_ENV=production - Tell Node.js to run in production mode

• --max_old_space_size=250 - Limit Node.js memory to 250MB

• Restart=on-failure - Automatically restart if NPM crashes

Step 19: Configure Services for Container Environment

In Docker, the internal process typically runs as root (even if the container doesn’t have host root access). NPM expects this and needs root to:

• Bind to ports 80/443

• Write to various system directories

• Manage nginx processes

Since we’re in an unprivileged LXC container, this “root” is actually restricted and safe.
Modify nginx to run as root (required in container)

sed -i ‘s/user npm/user root/g; s/^pid/#pid/g’ /usr/local/openresty/nginx/conf/nginx.conf

Update logrotate configuration

sed -i ‘s/su npm npm/su root root/g’ /etc/logrotate.d/nginx-proxy-manager

Reload systemd daemon to recognize new service

systemctl daemon-reload

Step 20: Start Services

Enable services to start on boot

systemctl enable openresty
systemctl enable npm

Start the services

systemctl start openresty
systemctl start npm

Give it about 5 seconds and then restart openresty to make sure it catches the config

systemctl reload openresty

Step 21: Verify Installation

Check service status

systemctl status openresty
systemctl status npm

Verify NPM is listening on port 81

ss -tulnp | grep :81

If you get nothing back - try reloading openresty one more time

systemctl reload openresty

Check for errors in logs

journalctl -u npm --no-pager | tail -20

Step 22: Clean Up

Remove temporary installation files

cd /
rm -rf /tmp/nginx-proxy-manager-*
rm -f /tmp/v2.12.6.tar.gz.tar.gz

Exit container

exit

Post-Installation

Accessing Nginx Proxy Manager

The web interface should now be accessible at:

• URL:

http://192.168.10.101:81

• Default Email: admin@example.com

• Default Password: changeme
